100m Bluetooth 5.0 Gateway Wifi support UDP, TCP and MQTT Communication
BLM-KTB602P supports the software remote upgrade function. It receives the signal strength (RSSI value) of the Bluetooth signal of the Bluetooth terminal through the Bluetooth gateway, and can calculate the distance between the Bluetooth terminal and multiple Bluetooth gateways, and then can achieve triangulation. It is widely used in medical treatment and elderly care. Sports, sports, fitness, education, family, and various industrial applications.
|
Model |
BLM-KTB602P |
|
Size |
124*40mm |
|
Power |
DC6-28V（2A） PoE |
|
Working Current |
280mA@12V（Include 4G） 180mA@12V |
|
Work Temperature |
-20℃~70℃ |
|
Port |
Network port, power port, reset button |
|
Wi-Fi |
|
|
Wi-Fi Protocol |
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
|
Data Rate |
IEEE 802.11 b Standard Mode: 1,2,5.5,11Mbps |
|
IEEE 802.11 g Standard Mode: 6,9,12,18,24,36,48,54Mbps |
|
|
IEEE 802.11n: 72Mbps @HT20 150Mbps @HT40 |
|
|
Receive Sensitivity |
HT40 MCS7: -67dBm@10% PER(MCS7) |
|
HT20 MCS7: -73dBm@10% PER(MCS7) |
|
|
54M: -76dBm@10% PER |
|
|
11M: -91dBm@ 8% PER |
|
|
TX Power |
IEEE 802.11n: 15dBm @HT40 MCS7 15dBm@HT20 MCS7 |
|
IEEE 802.11g: 16dBm |
|
|
IEEE 802.11b: 18dBm |
|
|
Wireless Security |
WPA/WPA2, WEP, TKIP, and AES |
|
Work Mode |
Bridge、Gateway、AP Client |
|
Bluetooth |
|
|
Bluetooth Protocol |
Bluetooth ® 5.0 |
|
Data Rate |
Uncoded: 1Mbps/2Mbps |
|
Wireless Security |
AES HW Encryption |
|
Connection Range |
100m |
|
TX Power |
0~+18dBm |
|
4G LTE |
|
|
Communication Protocol |
LTE-TDD/LTE-FDD/TD-SCDMA/UMTS/ EVDO/EDGE/GPRS/GSM/CDMA |
Features:
● Support PoE power supply or power adapter power supply;
● Support IEEE 802.11n, IEEE 802.11g, IEEE 802.11b protocols;
● Support Bluetooth ® 4.2/5.0;
● Integrated Bluetooth PA/LNA; support LTE-TDD/ LTE-FDD/ TD/ SCDMA/ UMTS/ EVDO/ EDGE/ GPRS/ GSM/ CDMA;
● One WAN/LAN adaptive port
